Discover the superior quality and performance of the ARI 100283506-021 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 100283506-021 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 100283506-021 :
At Impexron GMBH , we offer the 100283506-021 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 100283506-021 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ARI products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | ARI |
Product | 100283506-021 |
Internal code | IMP4519586 |
Technical specification | Figure 55,440 DN 50 ARI-STEVI 440 Straight type control valve with flanges 1.4408 DN 50 Nominal pressure: PN 40 Flange drilling: according to DIN PN40 Cone design: * parabolic cone Leakage class IV S1 Kvs value: 40 Characteristic curve: equal percent Execution: * Oxygen version Oil-free and grease-free for oxygen Spindle seal: * PTFE packing with BAM approval max. 60 °C Final acceptance test: APZ EN10204 3.1 Acceptance material testing: APZ EN10204 3.1 Drive: DP33 Complementary product description: * HP max. 14 bar TS max. 30°C Effectively (b.pneum.antr): Spring closes in case of air failure feathery. (bar) /stroke (mm): 2.30-3.70 stroke 20 mm Erford. Setting pressure (bar): 4.5 bar max. admissible Setting pressure (bar): 6 max. closing pressure (bar): * 14 Distance column length: L1=199mm Distance column spacing: 100 mm Coupling: M10 thread Positioner: EPS 33 Input signal: 4 - 20mA 2-wire Adjusted: 4 mA valve closed Inlet with ventilation air (bar): 6 bar |
