Discover the superior quality and performance of the Boll Kirch aquaBoll 6.18.3 Gr 419 DN 200 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The aquaBoll 6.18.3 Gr 419 DN 200 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of aquaBoll 6.18.3 Gr 419 DN 200 :
At Impexron GMBH , we offer the aquaBoll 6.18.3 Gr 419 DN 200 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the aquaBoll 6.18.3 Gr 419 DN 200 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | aquaBoll 6.18.3 Gr 419 DN 200 |
| Description | filter |
| Internal code | IMP5049990 |
| Technical specification | AquaBoll 6.18.3TI1 filter type Size 419TI1 Connection diameter DN 200TI1 Connection flanges according to hole pattern of connection flanges according to EN 1092-1 PN10TI1 Dimension sheet Z154933TI1 TIU2 --- OPERATING CONDITIONS --- Fluid to be filtered river waterTI1 PED 2TI1 fluid group Fluid type according to PED liquid TI1 Maximum flow rate 2700.00 l/minTi1 Operating overpressure 2.00 bArTi1 Maximum allowable pressure 10.00 BarTi1 Operating temperature not specifiedI1 Permit. Operating temperature min 0.00 °CTI1 Permission Operating temperature max 60.00 °CTI1 Pressure loss on clean sieves <0.1 bar at 2700.00 l/minTi1 Required prefiltration 10.00 mmTi1 TIU2 --- BACKWASH --- EigenmediumTI1 backwash medium Minimum operating pressure after filter 2.00 BarTi1 Flushing rate 8.20 l/s at 2.00 bArTi1 Motor power 0.090 kWTi1 Operating voltage 3 ph 400 VoltTi1 Frequency 50 Hz Control voltage 230 VoltTi1 Control without/NoneTi1 TIU2 --- CONSTRUCTION/APPROVAL --- Design and layout PED2014/68/EU AD-2000TI1 Article 4, paragraph 3TI1 Total volume 160.00 litresTi1 Empty weight 520 kgTi1 Pressure test according to Boll & KirchTi1 TIU2 --- MATERIALS --- Filter housing made from EN-GJS-400-18-LTTI1 Internal parts made of stainless steel Ti1 EPDMTI1 seal Seals made of EPDMTI1 TIU2 --- FILTER ELEMENTS --- Element type radial gap candle made of CrNi steel Ti1 No. of filter elements 12TI 1 CrNi steel candle headpiece and end piece, TIG welded TI1 Gap size 400 μmTi1 Screen area in operation 10010 cm²Ti1 Total screen area 10920 cm²Ti1 TIU2 --- ACCESSORIES --- Attached differential pressure indicator 4.46.2 (optical + electrical) TI1 EPDMTI1 differential pressure indicator sealant Differential pressure setting backwash 0.60 bar/Alarm 0.80 barTi1 Mud removal valve OHNETI1 --- Accessories/Connectors---Cat Inlet/outlet with adapter nInti1 Venting option 5.7.0 standard, Z149256 blind flange with screw ti1 G1/4"TI1 Emptying blind flange without boreTI1 Measurement point N5 option 5.6.0 standard, Z149256 plug-in connectionTI1 N6 measuring point blind flange without boreTI1 Measurement point N7 option 5.6.0 standard, Z149256 plug-in connectionTI1 --- ACCESSORIES/SOCKET ORIENTATION---CAT Assembly code S3D2TI1 --- ACCESSORIES/MOUNTING MATERIAL---CAT Cover screws/nuts and washers A4-70TI1 --- Accessories/differential pressure measurement---CAT DDA connection hose connection JaTi1 lifting eyes Nominal diameter flush valve 30 --- CORROSION PROTECTION --- Exterior primer 2K-Ep RAL 5005 100-200 μmTi1 Corrosion protection inside EpoxyTi1 TIU2 --- MARKING --- Operator/factory plate English/SpanishTI1 NachTi1 label - Machinery Directive CETI1 TIU2 --- DOCUMENTATION --- Language of the operating instructions in English/SpanishTI1 Declaration of conformity included |
