Discover the superior quality and performance of the ARCA 6H3-P1 ECOTROL-W4 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 6H3-P1 ECOTROL-W4 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 6H3-P1 ECOTROL-W4 :
At Impexron GMBH , we offer the 6H3-P1 ECOTROL-W4 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 6H3-P1 ECOTROL-W4 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ARCA products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | ARCA |
Product | 6H3-P1 ECOTROL-W4 |
Description | single seat control valve |
Internal code | IMP4796709 |
Technical specification | DN25 PN160 (=PN100) cover flange with cooling fins Connection on both sides: Form B2 Installation length: 230 mm Case material: 1.4408 Material cone: 1.4571 Seat material: 1.4571 1-stage parabolic cone, kvs 6.3 curve =% seat Ø 20 mm, Class IV leakage Package: Latty 6118/ETF Fig.01, DP = 5 bar Type 812 MFI-20.3-OE Pneumat. 20mm stroke control drive Function: air opens, spring force closes Membrane area: 320cm² 3 springs adjustment range 0.75-1.5 bar Ausf. B pipe reversible air flow M14 connection thread, socket Ø 48 mm Operating pressure: 2.5 # max. 6 bar Material certificate EN 10204 3.1 (ARCA AS 01) Approval EN 10204 3.1 (ARCA AS 01) Interpretation in accordance with PED2014/68/EU |
