Discover the superior quality and performance of the Warex Type DKZ 110 APS DN 100 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Type DKZ 110 APS DN 100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Type DKZ 110 APS DN 100 :
At Impexron GMBH , we offer the Type DKZ 110 APS DN 100 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the Type DKZ 110 APS DN 100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Warex |
| Product | Type DKZ 110 APS DN 100 |
| Description | Butterfly valve |
| Internal code | IMP4687290 |
| Technical specification | Construction length 39 mm to clamp between flanges in accordance with EN 1092, PN 10 Silumin housing 1.4408 stainless steel flap disc - with increased gap size - Stainless steel 1.4057 or higher quality shafts Shaft sealing with O-rings Brass shaft bearing - socket Black Buna CB sealing collar Replaceable in the housing Can be pneumatically clamped against the valve disc < APS > other attachments: Pneumatic rotary drive AT 60 DR double-acting Required control pressure 6.0 bar APS control 1002 1-channel control plan 0003475h 1x quick vent valve 1/4", with pressure regulator Throttle silencer 1/4" MS-Verz. 5/2 way solenoid valve function Norgren 2623077.3037 24 V DC, 1.6 W, IP 65 Namur version Limit switch box with 2 sensors P+F NBB2-V3-E2 3-wire, PNP, contact, 10-30 V DC, IP 67 built into the housing and wired to a terminal block To indicate the position to close (upper sensor) + Open (lower sensor) Characteristics: free-flowing, chemically neutral, Not prone to baking Working pressure: 3.0 bar Max. admissible Operating pressure: 4.0 bar (Ps) MAWP (Note: MAWP = Ausl. -Pressure) Operating temperature: 0 °C... + 60 °C (Ts) MAWT Surround. -Temperature: 0 °C... + 50 °C (Ta) Ex protection: no requirement evaluation of butterfly valves in accordance with DGRL 2014/68/EU, Diagram 7, certified module A2. The valves are subject to conformity assessment. Test pressure: design pressure x 1.1 bar for tightness |
