Discover the superior quality and performance of the Planetroll 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) :
At Impexron GMBH , we offer the 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Planetroll products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Planetroll |
Product | 4,0D2(Ex)dMR9-1Z011-6,864-1(40k6x80) |
Internal code | IMP4983786 |
Technical specification | consisting of: ------------- 1) “IE3" three-phase motor 2) Automatic transmission “p l a r o m a s t e r” 3) Control element 4) Baseboards 5) Spur gear 6) Painting specifications ----------------- Control element: right (motor terminal box - top) Design: B3 Installation position: 1 Speed range: 0 to approx. 175 rpm (50 Hz network) Output torques: approx. 293 Nm from 3 to 80 rpm approx. 150 Nm at 175 rpm Weight: approx. 132 kg Customs tariff number: 8501 52 20 ATEX version: Ex II 2G Ex h IIB T4 Gb (drive unit) Drive components ---------------- --1 1 PC three-phase motor on the drive side 4.0 kW, 300 rpm, 400 VD/690 VY, 50 Hz, IP 55, Isol.Kl.F, IE3, 3 PTC conductors, “Flameproof enclosure” II 2G Ex db eb IIC T4 Gb, size 112, B5-250. 302-046052 1 PC plaromaster type MR9 variable speed transmission drive side: for motor mounting IEC 100/112, B5-250 output side: B5 flange Ø250, output shaft Ø22K6x30/45.5 (for Z011) 302-044803 1 PC Control element type: HVK 7, handwheel (d0=100) with fine adjustment scale, rough scale 0 - 12, fine scale 0 - 100 302-046584 1 PC baseboards (1 pair) 502-153075 1 PC 2-stage helical gearbox type Z011 in foot version, reduction i = 6.864, (Drive-on sprocket Bo.D.22/Z=25); output shaft diam. 40k6 x 80, (housing cover diameter 250, 4x Bo.M12); (max. output torque M2=360 Nm), ATEX version: Ex II2 G/DC, k T4/120 °C. 6 1 PC 602-08767 + RAL 5003 painting - sapphire blue - |
