Discover the superior quality and performance of the Elaflex 45077528 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 45077528 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 45077528 :
At Impexron GMBH , we offer the 45077528 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 45077528 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Elaflex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Elaflex |
Product | 45077528 |
Description | EXPANSION JOINT |
Internal code | IMP4720179 |
Technical specification | NOMINAL DIAMETER: DN65 MM; MAXIMUM OPERATING PR ESSURE: PN25 BAR; FLANGES EXTERNAL DIAMETER: 185 MM; LENGTH: 130 MM; MAT ERIAL: STAINLESS STEEL 316; Bellows ROTEX Size DN DN 65 mm / 2½" Length BL 130 mm Flange 1 DIN PN 25 Material 1 Stainless Steel 316 Ti Flange 2 Same as first flange Material 2 Same as first material Limiters Without limiter Accessories Type VSD Flame Protection Without flame protection BellowsROTEX ROTEX expansion joints suitable for permanent use with hot heating water , cooling water and hot air. Approved according to DIN up to +100° C by 10 bar and up to +110° C by 6 bar. Temperature range (depending on medium) -40° C up to +130° C, temporaril y up to +150° C. Electrically dissipative. Not suitable for drinking water, cooling water with oil containing addit ives, oily compressor air, permanent effect of steam. Cover: EPDM, ozone proof, heat resistant Liner: EPDM, hot water resistant, seamless, abrasion resistant Marking: 2 red bands, ERV DN .., PN .., production date Size DNDN 65 mm / 2½" LengthBL 130 mm Flange 1DIN PN 25 Dimension: D: 185 mm, k: 145 mm, 8 holes, l: 18 mm Material 1Stainless Steel 316 Ti Flange 2Same as first flange Material 2Same as first material LimitersWithout limiter Without limiter (Standard) AccessoriesType VSD With vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient. Flame ProtectionWithout flame protection Without flame protection (Standard); MANUFACTURER 1: ELAFLEX; MODEL 1: ROTEX 65.25 SS VSD |
