Discover the superior quality and performance of the Scherzinger 4030-450-DM-37-2 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4030-450-DM-37-2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4030-450-DM-37-2 :
At Impexron GMBH , we offer the 4030-450-DM-37-2 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 4030-450-DM-37-2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Scherzinger |
| Product | 4030-450-DM-37-2 |
| Description | Magnetically coupled external gear pump |
| Internal code | IMP4437584 |
| Technical specification | Variant: GS, GD, Exd, KL medium Name: lubricating, non-corrosive Rated operating temperature: 20±5°C operating range inlet pressure: 1,000Mbara Min. operating point: 0.16 l/min at 437 rpm (7.7 Hz), 5 bar, 1 mPas Nom. operating point: 6.00 l/min at 1735 rpm (30.4 Hz), 5 bar, 1 mPas Max. operating point: 13.94 l/min at 3,500 rpm (61.4 Hz), 5 bar, 1 mPas specifications Explosion protection: 2014/34/EU - II 2G Ex h IIC Gb X//II 2D Ex h IIC Db X Preferred direction of rotation: left (ccw), pump shaft view Swallow volume: 4.5 c³/U Connections: DIN ISO 228, G 1/2” perm. Pump inlet pressure ፦0.9... 88 bar Operating temperature range ፦20 to 130°C Temperature sensor inclusion: with M6 thread on the splitting pot Temperature sensor inclusion: with M6 thread in the lid construction materials Housing material: 1.4404 Gear material: PEEK mod. Waves: 1.4571 plain bearings: PEEK mod. stat. Seals: PTFE Shaft seal: magnetic coupling, max.2 Nm Sm2Co17 magnets, encapsulated in 1.4404 three-phase motor Explosion protection: 2014/34/EU - II 2G Ex db eb IIC T4 Gb Engine size: IEC71 Engine bit: IMB34 Flange diameter: 140mm Rated power: 0.37 kW Rated speed: 2,850 rpm Voltage: 230/400V, 50Hz, 3~ Protection type: IP 55 Efficiency class: IE2 Temperature monitoring: with 3x PTC thermistors Terminal box: top, view of motor shaft Important notes Please install a coarse filter with 50 µm mesh size in front of the pump pump not suitable for liquids with magnetic particles Pump not suitable for particulate media The purity class of the medium should be at least 19/17/14 according to ISO 4406 |
