Discover the superior quality and performance of the Scherzinger 4030-450-B-DM-37-2 / 201882 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4030-450-B-DM-37-2 / 201882 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4030-450-B-DM-37-2 / 201882 :
At Impexron GMBH , we offer the 4030-450-B-DM-37-2 / 201882 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 4030-450-B-DM-37-2 / 201882 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Scherzinger |
Product | 4030-450-B-DM-37-2 / 201882 |
Internal code | IMP4897877 |
Custom code | 84136039 |
Technical specification | electric gear pump specifications • Preferred direction of rotation: left (ccw), view of the pump shaft • Intake volume: 4.5 cm³/U • Safety valve: 0... 6 bar • Connections: DIN ISO 228, G 1/2" • Permitted Inlet pressure: -0.92... 88 bar • Permitted differential pressure: 6 bar (depending on viscosity) • Operating temperature range: -20... 130°C construction materials • Housing material: 1.4404 • Gear material: PEEK mod. • Shaft material: 1.4571 • Bearing material: PEEK mod. • Stat. Seal material: PTFE • Shaft seal: magnetic coupling, max.2 Nm Sm2Co17 magnets, encapsulated in 1.4404 pump drive • Motor type: three-phase motor • Standard: IEC 72-1 • Engine size: 71 • Engine design: IMB34 • Flange diameter: 140 mm • Rated power: 0.37 kW • Rated speed: 2850 rpm • Voltage: 230/400V, 50 Hz • Protection class: IP 55 • Energy efficiency class: ≥ IE1 • Terminal box location: above • Painting: RAL 7035, light grey (primer) |
