Discover the superior quality and performance of the Boll Kirch 2.06.7.4.195.500 DN 80 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 2.06.7.4.195.500 DN 80 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 2.06.7.4.195.500 DN 80 :
At Impexron GMBH , we offer the 2.06.7.4.195.500 DN 80 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 2.06.7.4.195.500 DN 80 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | 2.06.7.4.195.500 DN 80 |
| Description | filter |
| Internal code | IMP4202608 |
| Technical specification | 366160 Commodity code: 842123 Filter type: 2.06.7.4 Case Size (G.Q): 195,500 Connection diameter: DN 80 Flanges to: WN165, square flange Dimension sheet: Z116495 — OPERATING CONDITIONS — Fluid to be filtered: oil fluid group according to PED: 2 Fluidart according to PED: liquid Max. flow rate: 300.00 l/min Operating pressure: 6.00 bar Maximum allowable pressure: 10.00 bar Operating temperature: 38.00 °C allowance Operating temperature min: 1,00 °C allowance Operating temperature max: 80.00 °C — CONSTRUCTION/ACCEPTANCE — Design and layout: PED2014/68/EU AD-2000 Art. 4, para. 3 Capacity of the container 2 x: 17.00 litres Empty weight: 130 kg Pressure test according to: Boll & Kirch with certificate Material: EN 10204/2.1 Filter housing made of: EN-GJS-400-15 Type of switch valve: Chick tap switching Material of the switch valve: EN-GJS-400-15 Internal parts of the switch valve: EN-GJS-400-15 Lid seals made: Viton Circuit seals off: Viton — FILTER ELEMENTS — Item Type: Ring Screen Element Material of the element: steel/aluminium. Cloth of: 1.4401 Tissue Number: 35 Filter fineness: 500 μm Screening area 2x: 2984 cm² — ACCESSORIES — Heated filter housing: steam pergil. Operating pressure in boiler room: 14.00 bar pergil. Operating temperature in boiler room: 200.00 °C Attached differential pressure indicator: without Opposites. Screws and gaskets: included: drilled for DN80 — CORROSION PROTECTION — Exterior base coat: 2K-Ep RAL 5005 Inner Preservation: Shell Tellus S2 M 32 |
