Discover the superior quality and performance of the Boll Kirch 2.05.5.265.500 DN 100 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 2.05.5.265.500 DN 100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 2.05.5.265.500 DN 100 :
At Impexron GMBH , we offer the 2.05.5.265.500 DN 100 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 2.05.5.265.500 DN 100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | 2.05.5.265.500 DN 100 |
| Internal code | IMP3281992 |
| Weight | 235 |
| Technical specification | Filter type: 2.05.5 Case Size (G.Q): 265,500 Nominal connection width: DN 100 Connection flanges acc. to: DIN 2501 PN 10 Dimension sheet: Z100403 Arrangement of flanges: When ordering, please specify whether arrangement No. 1 or No. 2 is desired. — OPERATING CONDITIONS — fluid to be filtered: lubricating oil fluid group according to PED: 2 Type of fluid according to PED: liquid Max. flow rate: 1,000.00 l/min Permissible operating pressure: 10.00 bar Perm. Operating temperature min: 0.00 °C Perm. Operating temperature max: 60.00 °C — CONSTRUCTION/ACCEPTANCE — Construction and design: PED2014/68/EU AD-2000 : Art. 4, para 3 Volume of container 2x: 35.00 liters Pressure test according to: Boll & Kirch with certificate Material certificates: EN 10204/3.2 — MATERIALS — filter housing manufactured from: EN-GJS-400-15 Type of changeover valve: plug tap changeover Material of changeover valve: EN-GJS-400-15 Switch Valve Internal Parts: EN-GJL-250 Lid seals made of: Perbunan circuit seals made of: Perbunan — FILTER ELEMENTS — Element type: jacket sieve element Material of the element: steel/aluminum Fabric made from: 1.4401 Tissue number: 300/250 Filter fineness: 37 μm Screen area 2x: 11762 cm² — ACCESSORIES — Attached differential pressure indicator: 4.36.2 (optical + electric) Differential pressure setting: cleaning 0.6bar/alarm 0.8bar Counterflan. Screws and gaskets: included — CORROSION PROTECTION — Base coat outside: 2K-Ep RAL 5005 Interior preservation: hydraulic oil ISO VG 32 — MARKING — Operator/factory sign: German/English Filter without CE mark: — DOCUMENTATION — Language of the operating instructions in: German/English Operating instructions: 1x pdf Acceptance certificates/certificate: 1x |
