Discover the superior quality and performance of the Scherzinger 251BRLS/K12/M075/F12 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 251BRLS/K12/M075/F12 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 251BRLS/K12/M075/F12 :
At Impexron GMBH , we offer the 251BRLS/K12/M075/F12 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 251BRLS/K12/M075/F12 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Scherzinger |
Product | 251BRLS/K12/M075/F12 |
Internal code | IMP4853677 |
Custom code | 84136039 |
Technical specification | specifications • Direction of rotation • Preferred direction of rotation on the right (cw), view of the pump shaft • Left (ccw) without the pressure relief valve working • Discharge volume: 10.9 cm³/U • Safety valve: 1 - 8 bar • Connections: DIN 2673, DN25, PN10 • Permit Pump inlet pressure: -0.7... 10 bar • Operating temperature range • permanently -15 to 160°C • up to 300°C for a short time Construction materials • Housing material: EN GJS 400 • Gear material: EN 11SMn30 • Shafts: EN 11SMn30 • Bearings: multi-layer bearings • State Seals: FKM • Shaft seal: • Stuffing box packaging • PTFE/graphite foot pump on base plate with motor • mounted on gray cast iron base plate • including coupling and clutch protection • Mounted on a standard motor • Motor frame size: IEC80 • Engine beard: IMB3 • Nominal output: 0.75 kW • Rated speed: 1,425 1/min • Voltage: 380-420 V/220-240 V, 50 Hz, 1400 rpm, 0.75 kW 440-480 V/254-280 V, 60 Hz, 1680 rpm, 0.90 kW • Protection class: IP 55 • Efficiency class: IE3 • Terminal box: above |
