Discover the superior quality and performance of the Burkert 237770 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 237770 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 237770 :
At Impexron GMBH , we offer the 237770 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 237770 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Burkert |
| Product | 237770 |
| Description | 2/2-way solenoid valve, force-controlled |
| Internal code | IMP4690050 |
| Custom code | 84818079 |
| Technical specification | GENERAL INFORMATION --------------------- 2/2-way solenoid valve, force-controlled Article number: 237770 Weight: 0.377 kg Statistical product number: 84818079 MODE OF ACTION ------------- Fluidic line connection number: 2 Valve function Number of switching positions: 2 Valve function: A - closed in rest position - pressure port 1 (P/NC) Manual operation: No PROCESS/LINE CONNECTION ---------------------------- Line connection 1 type: internal thread Line connection 1 Thread name: 1/2 Line connection 1 Thread type: G Line connection 2 type: internal thread Line connection 2 Thread type: G Line connection 2 Thread name: 1/2 TENSION -------- Voltage min/Nominal voltage: 230 V Max. voltage/Nominal voltage: 230 V Voltage frequency: 50 Hz Positive voltage tolerance: 10% Negative voltage tolerance: 10% AC voltage: Yes DC voltage: No Battery Voltage: No MATERIALS ---------- Valve seat material: stainless steel Main valve material in contact with the medium: brass Control of material in contact with medium: PA (polyamide) PRESSURE & TEMPERATURE ------------------ Backpressure-proof version: No Nominal pressure min: 0 bar Max. nominal pressure (liquid): 10 bar Nominal pressure (DIN EN 1333): PN 10 Minimum medium temperature: -10°C Max. medium temperature: 80°C Ambient temperature min: -10 °C Ambient temperature max: 55°C SEALING MATERIAL ----------------- Seat Seal Material Category: Elastomers Seat seal material: NBR (nitrile rubber) Outer sealing Material: NBR (nitrile rubber) Seal pilot material: NBR (nitrile rubber) APPROVALS ----------- Rated power: 8 W NOMINAL SIZE (KV VALUE) ------------------- Kv value (water): 1.9 m3/h Pre-control nominal size (mm): 1.2 mm Main valve size 1 (P) (mm): 10 mm Main valve size 1 (inch): 3/8 inch DEVICE PROPERTIES ------------------- Type: 6213 Drive type: lift anchor Operation: servo-controlled Media separation: No Air flow: via seat Main valve operating principle: diaphragm valve Valve construction: valve complete Switch function: on/off Open switching time min: 10 ms Open switching time max.: 30 ms Close switching time min: 100 ms Close switching time max.: 150 ms Nominal operating mode/duty cycle: 100% Vacuum version: No Analysis version: No Valve setting opening time: No Valve setting closing time: No Oil burner valve: No Steam version: No Central-bolted pilot control: Yes Core guide: slide ring Installation length: 50 mm Main valve with integrated strainer: No ELECTRICAL CONNECTION ---------------------- Electrical connection type: connector diagram form A according to DIN EN 175301-803 Electrical connection Number of contacts: 2 + protective conductor Device outlet included: not included Electrical connection position: left in flow direction DEGREE OF PROTECTION --------- Protection class (IP max. with suitable connection): IP65 COIL (CORE) ------------ Low-noise version: No Spool type: plugged in Spool material (jacket): PA (polyamide) Spool size: 32mm coil circuit surge protection: none Coil circuit rectifier: No Coil circuit pole protection: No Freewheeling diode coil circuit: No Drive thermal insulation class: B Switch-on capacity AC: 24 V·A Rated power AC: 8 V·A Part in contact with the medium Core Material: stainless steel Part in contact with the medium Plug Material: stainless steel |
