Discover the superior quality and performance of the Burkert 20061787 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 20061787 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 20061787 :
At Impexron GMBH , we offer the 20061787 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 20061787 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Burkert |
Product | 20061787 |
Internal code | IMP5033280 |
Technical specification | 2/2-way angle seat valve manually operated 2920-SA-40.0EE-VASODH-N5E1-S-0-0-2-0-1 AF93+NK51 Type 2920 2920 Drive function S Switch drive open/close Case type A tilted seat Nominal size 40.0 40 mm EE PTFE sealing material Material VA stainless steel SODH welding cable connection 38.1 x 1.65 according to ASME BPE, DIN 11866 series C (can be used for BS4825-1) Arm interface. /Drive N5 nipple thread M58 x 2 (standard DN 40) Interface on the E1 spindle D10 drive Handwheel diameter S Ø 45 mm Antr.mod.opt. el. feedback 0 without electrical feedback Antr.mod.opt. Stroke limit 0 without Antr.mod.opt. position indicator 2 optical Antr.mod.opt. Locking point 0 without Product identification 1 data matrix code Special feature AF93 case OD tubing long NK51 packaged seal included Pressure min 0 bar Pressure max 16 bar KV 38 m3/h Medium temperature min -10 °C Medium temperature max 185 °C Ambient temperature min -10 °C Ambient temperature max 60 °C |
