Discover the superior quality and performance of the United Electric Controls 1XTX00P15 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1XTX00P15 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1XTX00P15 :
At Impexron GMBH , we offer the 1XTX00P15 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 1XTX00P15 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply United Electric Controls products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | United Electric Controls |
Product | 1XTX00P15 |
Description | Pressure transmitter series ONE |
Internal code | IMP4174304 |
Custom code | 90262030 |
Technical specification | Model: 1XTX00-P-15 Measuring range: 0... 20.68 bar Signal output: 4... 20 mA (NAMUR NE 43) + HART 7 overpressure resistant up to: 41.4 bar Ambient temperature ፦40... +85°C Media temperature ፦40... +125°C materials Pressure sensor: stainless steel 316L Piezo with welded membrane (without seal) Process Connection: 1/2" NPT F/Stainless Steel 316L Housing: Epoxy coated die-cast aluminum with integrated LCD multi-display and menu-guided programming or HART Degree of protection: IP 66/NEMA 4X electr. data Power supply: 20... 40 Vdc (via 4... 20 mA signal) Approval (s) Europe Explosion protection: II 2 G Ex db IIC T5 - II 2 D Ex tb IIIC T+90°C Db Certification: DEMKO 09 ATEX 0813748X/IECEx Explosion protection: II 3 G Ex nA IIC T4 Gc Certification: DEMKO 15 ATEX 1483 Approval (s) North America Explosion protection: CLASS I, DIVISION 1, GROUPS A, B, C & D; CLASS II, DIVISION 1, GROUPS E, F, G; CLASS III CLASS I, ZONE 1, AEx d IIC T5; Ex d IIC T5; CLASS I, DIVISION 2, GROUPS A, B, C & D; CLASS II, DIVISION 2, GROUPS E, F, G; CLASS III CLASS I, ZONE 2, GROUPS AEx nA IIC T4; Ex nA IIC T4 Approval: UL/Cul/CSA/CRN |
