Discover the superior quality and performance of the DAYTON 1LPL1 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1LPL1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1LPL1 :
At Impexron GMBH , we offer the 1LPL1 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 1LPL1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply DAYTON products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | DAYTON |
| Product | 1LPL1 |
| Description | DC Gearmotor |
| Internal code | IMP4924321 |
| Technical specification | Gearmotor Voltage 90V DC Motor Type Permanent Magnet DC Shaft Orientation Parallel Enclosure TENV Nameplate RPM 6.5 RPM Gearmotor Shaft Type Single Gearmotor Shaft Orientation Parallel Voltage 90VDC Gearmotor Enclosure Totally Enclosed Nonventilated Gear Ratio 267:1 Full Load Amps 0.84 A Reversible Shaft Output No Gearmotor Mounting Position All Angle Finish Unpainted Seals O-ring Type on Output Shaft Housing Material Die Cast Zinc Mounting All Position Rotation CW/CCW Max. Ambient Temp. 40 Degrees C RPM Range 0 to 15 Tachometer Feedback No Gear Material Hardened Steel, Phenolic Insulation Class F Standards C-UL Recognized, UL Recognized Brushes Externally Replaceable Max. Torque 500 in-lb Input HP 1/15 Bearings Ball on Motor, Porous Bronze Sleeve on Case Gearmotor Rotation CW/CCW Gear Case Die Cast Zinc Overhung Load 250 lb Shaft Single Output Rear Shaft Encoder/Pulse Generator Mounting No Replacement Brushes 6YHY6 Thermal Protection None Lubrication Grease Filled Seal Type O-Ring Type on Output Shaft Operating Voltage 90V DC Keyway Type Woodruff #605 Bearing Type Ball on Motor, Porous Bronze Sleeve on Case Maximum Ambient Temperature 40 Degrees C Input Horsepower 1/15 hp Overhung Load Capacity 250 ft-lb Maximum Torque 500 in-lb Full Load Current 0.84 A Motor Enclosure Totally Enclosed Nonventilated Nameplate Speed 6.5 RPM Housing Material Finish Unpainted Replaceable Motor Brushes Yes Mounting Orientation Any Angle |
