Discover the superior quality and performance of the Warex WX2000 / DKZ 110
The WX2000 / DKZ 110
Key Features of WX2000 / DKZ 110
At Impexron GMBH , we offer the WX2000 / DKZ 110
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the WX2000 / DKZ 110
Important Notice: While we supply Warex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Warex |
Product | WX2000 / DKZ 110 <APS> DN 300 |
Description | butterfly valve |
Internal code | IMP4580751 |
Custom code | 84818085 |
Technical specification | Construction length 78 mm for clamping between flanges in accordance with EN 1092, PN 10 Silumin housing with grounding connection Stainless steel flap plate 1.4408 grounded - polished Ra < 0.8 μm - - with increased gap size - 1.4057 or higher grade stainless steel shafts Shaft sealing with O-rings Brass shaft bearing - socket White NBR sealing collar replaceable in the housing Can be pneumatically clamped against the flap disc < APS > suitable for foodstuffs, in accordance with Regulation (EC) No 1935/2004 further attachments: pneumatic rotary actuator AT 300 DR double-acting required control pressure 6.0 bar El. /peum. APS flap control ** 1 signal control ** Execution in accordance with tax plan 0003475 with 2x quick exhaust valve, with pressure regulator, with throttle silencers 5/2-way solenoid valve function Airtec KN-05-510-HN-B12 24 V DC, IP 65 Namur version with magnetic coil 23-SP-040-B12 Wet Magnet 0558 50.1-00/5147 Cat II 3G EEx nA II T5 Cat II 3D T 95°C Assembly kit/ET kit for sensors 2 pieces M18 Sensing range < 5 mm, can be installed flush to the “Open-Close” position indicator incl. Stainless steel perforated metal cover as protection against contact - but without a sensor - |
