Discover the superior quality and performance of the Leybold 11406 / TRIVAC D 16 B DOT with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 11406 / TRIVAC D 16 B DOT is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 11406 / TRIVAC D 16 B DOT :
At Impexron GMBH , we offer the 11406 / TRIVAC D 16 B DOT at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 11406 / TRIVAC D 16 B DOT ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leybold products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Leybold |
| Product | 11406 / TRIVAC D 16 B DOT |
| Description | pump |
| Internal code | IMP571089 |
| Weight | 1 |
| Custom code | 84141025 |
| Technical specification | Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed, i.e. no use of elastomer seals, which can be chemically attacked. The TRIVAC B The pump has a hydropneumatic suction port valve for vacuum protection and via a gas ballast device, with which it It is possible to pump condensable vapors. Engine certification: CSA, UR Pump certification: CE RoHS compliant Technical data: Pumping speed in accordance with DIN 28400:16.5 m³/h (50 Hz)/19.8 m³/h (60 Hz) Ultimate total pressure without gas ballast: < 6 · 10-1 mbar Ultimate total pressure with gas ballast: < 9 · 10-1 mbar Sound level according to DIN 45 635 without/with gas ballast: 54/ 56 dB (A) Dimensions (LxWxH): 510 x 186 x 250 mm Oil filling min/max: 0.5/1.0 l Includes oil filling with DOT 4 Motor data: Nominal power of the three-phase motor 750 W Rated speed: 1425 min-1 (50 Hz)/1730 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 3.8 A/200-240 V; 60 Hz; 3.4 A 200 V; 50 Hz; 3.8 A (IE3= 82.5%) 208-240 V; 60 Hz; 3.4 A (IE3= 85.5%) 380-400 V; 50 Hz; 1.9 A/380-480 V; 60 Hz; 1.9 A 380-400 V; 50 Hz; 1.9 A (IE3= 82.5%) 416-480 V; 60 Hz; 1.7 A (IE3= 85.5%) Suitable for line voltages +/- 10% Suction flange: DN25KF can be used horizontally and vertically Outlet flange: DN25KF can be used horizontally and vertically Cooling: air equipment: Manual gas ballast device (on/off) Inert gas connection for the M16x1.5 gas ballast Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug |
