Discover the superior quality and performance of the S+S REGELTECHNIK 1101-1142-0009-900 / ATM2-I with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1101-1142-0009-900 / ATM2-I is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1101-1142-0009-900 / ATM2-I :
At Impexron GMBH , we offer the 1101-1142-0009-900 / ATM2-I at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 1101-1142-0009-900 / ATM2-I ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply S+S REGELTECHNIK products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | S+S REGELTECHNIK |
| Product | 1101-1142-0009-900 / ATM2-I |
| Description | Outside temperature transmitter |
| Internal code | IMP3776949 |
| Weight | 0.16 |
| Custom code | 90251900 |
| Technical specification | Power consumption < 1,0 W/ 24 V DC < 2,2 VA/ 24 V AC Voltage supply 15...36 V DC depending on working resistance, residual ripple stabilised ± 0.3 V Temperature deviation typically ± 0.2 K at +25 °C Working resistance Ra (ohm) = (Ub -14 V)/ 0.02 A for I variant Sensor Pt1000, DIN EN 60751, class B (Perfect Sensor Protection) Connection type 2- or 3-wire connection Ambient temperature Measuring transducer –30...+70 °C Process connection by screws Protective tube stainless steel V4A (1.4571), Ø 6 mm, NL = 65 mm Electrical connection 0.14 - 1.5 mm² via terminal screws Cable gland M 16 x 1.5, including strain relief, exchangeable, max. inner diameter 10.4 mm Permissible air humidity < 95 % RH, non-precipitating air Protection class III (according to EN 60 730) Output 4...20 mA Measuring ranges multi-range switching with 8 switchable measuring ranges, see table (other ranges optional) operating range –30...+70 °C with manual zero point correction (± 10 K) Cable connection cable gland, plastic (M 16 x 1.5; with strain relief, exchangeable, max. inner diameter 10.4 mm) or M12 connector according to DIN EN 61076-2-101 (optional on request) Housing plastic, UV-stabilised, material polyamide, 30 % glass-globe reinforced, with quick-locking screws (slotted/ Phillips head - combination), colour traffic white (similar to RAL 9016) Housing dimensions 72 x 64 x 37,8 mm (Tyr 1) Protection type IP 65 (according to EN 60 529) Housing tested, TÜV SÜD, Report No.713139052 (Tyr 1) Standards CE conformity, electromagnetic compatibility according to EN 61326, according to EMC Directive 2014/ 30/ EU |
