Discover the superior quality and performance of the KFG Level AG UTN-C00C with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The UTN-C00C is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of UTN-C00C :
At Impexron GMBH , we offer the UTN-C00C at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the UTN-C00C ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply KFG Level AG products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | KFG Level AG |
| Product | UTN-C00C |
| Description | Top mounted level indicator |
| Internal code | IMP5034077 |
| Custom code | 90261089 |
| Technical specification | UTN-3"/150/RF-L630/M405-V42x2-MRA-ZTS75/200/PN16/UTN/K72-E Overtank indicator type UTN-C00C Approval: ATEX Ex h; IBEXU20ATEX1066 X II 1/2G Ex h IIB T6... T1 Ga/Gb, II/2D Exh IIIC T68°C... T360°C -/Db Pressure: 10 bar; temperature: -10°C... 100°C; density, medium: 1000 kg/m³ Interpretation: DGRL 2014/68/EU (AD2000) Classification according to DGRL 2014/68/EU: None Test pressure: 15 bar Chamber dimensions: 42.4 x 2 mm stainless steel 1.4571 (316Ti) Process connection: ASME B16.5 3" Class 150 form RF flange Installation length (L): 630 mm Measurement range: 405 mm Overhang above (T): 100 mm Bottom overhang (U): 145 mm Length of guide sleeve (X): 25 mm Type plate: laser marked aluminum ZTS75/200/PN16/UTN/K72 Bypass swimmer Float material: titanium Test pressure: 13 bar (float only) Density, medium: 800 kg/m³ UTN magnetic system: K72 Push rod: titanium, Ø 10 x 1 mm Push rod length: 539 mm UTN float weight: 345 g surfaced height (F): 90 mm MRA-M405 BMD-SA bypass indicator Measurement range: 405 mm Case material: anodized aluminum Indicator: red/white rollers Lens: Makrolon PC Acceptance test certificate 3.1 in accordance with EN 10204 Certificate type: Acceptance test certificate DIN EN 10204 3.1 Certificate language: English and German Certificate/Testimonial for: Overtank indicator Material Certificate: Pressure-bearing metallic in contact with media Components with pre-supplier certificate (melt analysis) Pressure and strength test: hydrostatic internal pressure test ***Drawing for review and approval |
