Discover the superior quality and performance of the Planetroll 0,55D2MR3-3(14h6x30) with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 0,55D2MR3-3(14h6x30) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 0,55D2MR3-3(14h6x30) :
At Impexron GMBH , we offer the 0,55D2MR3-3(14h6x30) at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 0,55D2MR3-3(14h6x30) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Planetroll products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Planetroll |
Product | 0,55D2MR3-3(14h6x30) |
Internal code | IMP4986386 |
Custom code | 85015100 |
Technical specification | 602-12828 Planetroll variable speed drive unit Type 0.55D2MR3-3 (14h6x30) planetroll drive unit, as delivered with F no.: AB03961/2, but with a new motor in “IE3". consisting of: ------------- a) Three-phase motor with efficiency class IE3 b) “p l a r o m a s t e r” variable transmission specifications Control element: right Design: B14 Installation position: 4 Speed range: 0 to approx. 1200 rpm (50 Hz network) Output torques: approx. 6 Nm from 20 to 650 rpm approx. 3.3 Nm at 1200 rpm Weight: approx. 13 kg/pc Customs tariff number: 8501 51 00 Drive components ----------------------- 501-162161 1 PC three-phase motor 0.55 kW, 2840 rpm, 230/400 V, 50 Hz; IP 55, insulated class F/B, with 3 built-in cold conductors; energy efficiency class IE3; 220-245/380-420V 50Hz//220-280/380-480V 60Hz, frame size 71, B14-105. 302-019862 1 PC plaromaster type MR3 variable speed gearbox drive side: for motor mounting size 71, B14 - Ø105 output side: B14 - Ø120, output shaft diameter 14h6 x 30 302-014663 1 PC HVK 5 type control element for AR2-AR5/MR3+MR5: handwheel (d0=50) with fine adjustment scale; rough scale 0 - 12, fine scale 0 - 100 |
