Discover the superior quality and performance of the Planetroll Typ 0,25D4MR3-1/2(160,14h6x30) with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Typ 0,25D4MR3-1/2(160,14h6x30) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Typ 0,25D4MR3-1/2(160,14h6x30) :
At Impexron GMBH , we offer the Typ 0,25D4MR3-1/2(160,14h6x30) at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the Typ 0,25D4MR3-1/2(160,14h6x30) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Planetroll products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Planetroll |
Product | Typ 0,25D4MR3-1/2(160,14h6x30) |
Description | Variable speed transmission drive unit |
Internal code | IMP4689089 |
Custom code | 8501 51 00 |
Technical specification | consisting of: 1) Three-phase motor 2) Control transmission “p l a r o m a s t e r” 3) Control element 4) Baseboard 5) Painting Technical data: Control element: right Design: B5 Installation position: 1 Speed range: 0 to approx. 600 rpm Output torques: approx. 7.0 Nm from 10 to 220 rpm approx. 3.1 Nm at 600 rpm Drive components 1 501-15237 3 PCS Three-phase motor on the drive side 0.25/0.28 kW, 1395/1695 rpm, 230/400 V, 50 Hz, 1.33/0.76 A 460 V 60 Hz 0.75A, IP 55, Isol.Kl.F, energy efficiency class IE2, 1 cold-conductor temperature sensor,; Aluminum terminal box, 1x M25x1.5/1x M16x1.5 cable entry, size 71, B14-105 2 302-01923 3 PCS Plaromaster type MR3 variable speed gearbox on the drive side: for BG 71, B14-105 engine mounting output side: flange: B5-Ø160, output shaft 14h6 x 30 3 302-01466 3 PCS Control element type HVK 5 for AR2-AR5/MR3+MR5: Handwheel (d0=50) with fine adjustment scale; rough scale 0 - 12, fine scale 0 - 100 4 302-02300 3 PCS Baseboards (1 pair) for MR3 variable speed transmission 5 602-08879 3 PCS + RAL 9006 white aluminum painting |
